Laser Concrete Paver with Full-time Electrical System (FDJP-24D)

  • Laser Concrete Paver with Full-time Electrical System (FDJP-24D)
  • Laser Concrete Paver with Full-time Electrical System (FDJP-24D)
  • Laser Concrete Paver with Full-time Electrical System (FDJP-24D)
  • Laser Concrete Paver with Full-time Electrical System (FDJP-24D)

Laser Concrete Paver with Full-time Electrical System (FDJP-24D)

Product Description

Laser Concrete Paver with Full-time Electrical System  FDJP-24D

Product Description

Laser concrete paver machine is used in large area concrete construction, such as workshop, supermarket, warehous, airport, playground and so on. This machine can satisfy the construction requirements of large area and high planeness and levelness.

The laser control system can monitoring the height of floor by laser feedback adjusting. This ensures the level flatness,dense and homogeneous of the floor.

Technical Parameters



Model

FDJP-24D Laser Concrete Paver

Engine Model

HONDA GX200 Electric Start

Type

4 Stoke, OHV, Single Cylinder Gasoline Engine

Power

2.8kw

Lubricant L

0.6L

Fuel Consumption

300g/kwh

Drive

Reducer+Walking Motor

Wheel

Solid Tire/ Beach Tire

Running Speed

0-40m/min

Working Speed

5m/min

Screed Head Type

Rocking type

Screed Width

2500mm

Exciting Force

500N

Vibration Frequency

50Hz

Screed Plate Level Control

Electric Automatic Control

Laser Control Type

Microcomputer Laser Scan

Operation Mode

Walk-behind

Forward and Backward

Switch Control, CVT

Steering

Hydraulic Control

Fuel Oil Volume

12L

Machine Size(LxWxH)

2860mmX2280mmX1172mm

Weight

240kg

Features:

1)  Laser screed can pave the concrete base,trowel the concrete and vibrate it to smooth. The work efficiency will be improved because the machine can set the height of elevation automatically, and the operator can finish the working area fast and efficiency.

2)  This product is small, light, easy to operate, with reasonable price.

3)  Adopts imported Leica laser transmitter and Moba receiver, which have good performance.

4) Two kinds of tyres optional: Solid Tire or Beach Tire

Product Photos



Similar Products

Ride on laser screed & Walk-behind laser screed

Worksite



Packaging & Shipping
Thanks to pay attention to our products. We will be appreciate to hear from you for any question. If you need any information, please don’t hesitate to contact us, we will at your service 24hours.

Jining Furuide Machinery Manufacturing Co., Ltd.

 Jining Furuide Machinery Manufacturing CO., LTD, established in 2008, is a professional manufacturer engaged in the research, development, production, sale and service of vibratory road roller,concrete screeds,portable light tower,power trowel, concrete cutter and other light construction machines.We are located in Hometown of Confucius and Mencius Jining city of Shandong province with convenient transportation access. Covers 40 acres area, over 20,000 m² production workshop. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In recent years, our company has introduced a series of advanced equipment including concrete laser screed and crack filling machine. In addition, we have obtained certificates of C E, I S O 9 0 0 1 and 10 national patents of vibratory road roller.Selling well in all cities and provinces around China and our products are also exported to clients in such countries and regions as South Korea,the United States, Europe,Southeast Asia,Africa and South America. We also welcome O E M and O D M orders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.We are looking forward to forming successful business relationships with new clients around the world in the near future.
